1.25Gb/s CWDM 200KM SFP Transceiver and Optical Module

FiberRoad Technology Co., Ltd.
Contact Now

1.25Gb/s CWDM 200KM SFP Transceiver and Optical Module

Brand Name : FR

Model Number : FS-1512-200D

Certification : CE,FCC

Place of Origin : China

MOQ : 5PCS

Price : $10/pcs

Supply Ability : 1000pcs/month

Delivery Time : 3-5DAYS

Packaging Details : 1CTN/900PCS/21.40KGS/56*40*32CM

Contact Now

Features:

  • Up to 1.25Gb/s Data Links
  • Hot-Pluggable
  • Duplex LC connector
  • Up to 150km on 9/125μm SMF
  • 1470~1610nm CWDM DFB laser transmitter
  • APD Receiver
  • Single +3.3V Power Supply
  • Monitoring Interface Compliant with SFF-8472
  • Maximum Power <1W
  • Commercial operating temperature range: -0°C to 70°C Version available
  • RoHS compliant and Lead Free

1.25Gb/s CWDM 200KM SFP Transceiver and Optical Module

Applications:

  • Metro/Access Networks
  • 1.25 Gb/s 1000Base-EZX Ethernet
  • 1×Fibre Channel
  • Other Optical Links

Description:

FiberRoad’s FS-XX12-200D Transceiver is a high performance, cost effective module which have a duplex LC optics interface. Standard AC coupled CML for high speed signal and LVTTL control and monitor signals. The receiver section uses an APD receiver and the transmitter uses a CWDM DFB laser, up to 36dB link budge ensure this module 1000Base Ethernet 200km application.
