Brief Introduction
FR-5N3224-P is a new generation Power over Ethernet switch with 24-Port 10/100/1000Base-TX and 2 Gigabit SFP that
provide stable and reliable Ethernet transmission offered by Fiberroad, with high quality design and reliability. It is positioning in the broadband network market, to offer and realize Ethernet data exchange, convergence and long-distance optical transmission
with efficient bandwidth and reliable fiber optic network solutions for users.
Features
> 24x10/100/1000Base-TX RJ45 ports, 2xGigabit SFP/ 24xPoE
> AI Extend: Extend 250M transmission
> AI QoS: Video data first, more fluent transmission
> AI VLAN: Avoid the internet storm and enhance the network ability
> AI PoE: Automatic self checking, reboot the device while find it fake dead
> Support Auto-MDIX, and full/half duplex self-negotiation mode
> Provide SC/FC/ST/LC interface fiber port, support single/dual fiber transmission
> Support 10K bytes giant frame, compatible with various extension protocol
> 8K MAC address table
> Support IEEE802.3az energy efficient Ethernet technology
> Support IPv6 Protocol
> Electric 4KV surge protection
> Complete status indicator, working state at a glance
> 1U rack-mount type
Specification
| Physical Port |
| RJ45 Port and Speed | 24x10/100/1000Base-TX |
| Fiber Port and Speed | 2xGigabit SFP |
| Parameters |
| Ethernet Standards | IEEE802.3 IEEE802.3u IEEE802.3z IEEE802.3ab IEEE802.3x IEEE802.3az IEEE802.3Qad IEEE802.3ah IEEE802.1X IEEE802.1Q IEEE1588 |
| Packet Buffer | 4M |
| Maximum Packet Length | Up to 10K |
| MAC Address Table | 8K |
| Transmission Mode | Store and Forward (full/half duplex mode) |
| Exchange Property | Delay time: < 7μs Backplane bandwidth: 56Gbps; Packet forwarding rate: 47.616Mpps |
| PoE |
| PoE Standard | 24x IEEE 802.3af/IEEE 802.3at PoE |
| Power Budget | Max. PoE output power budget 30W |
